Intelligent Dimming Switch

Introduction:

       Intelligent dimming switch has been widely applied to home lighting, which can not only control the switch, light intensity and color temperature by buttons, infrared remote control or mobile phone, but also set different scene modes according to user habits.

       SinOne intelligent dimming solution SC95F852x series is based on high-performance 8bit MCU, supporting 23 TK circuits, only 2 TK circuits are needed to realize slider control function which can smoothly control the light brightness and color temperature; IOs equipped with sink current drive capability are able to drive infrared sensing function to realize infrared remote control; up to 4 UARTs support communication module connection and remote control.

       Meanwhile, SinOne EasyCodeCube has been embedded in the application template of the intelligent dimming switch, which can quickly complete product development without any code.


Scheme Features

ØSupport button/slider/wheel operations

ØHighly sensitive and reliable Touchkeys, passing 10V dynamic CS

ØVarious interfaces, available for connecting communication modules and sensors

ØSupport OTA upgrading

ØAll I/Os feature sink current drive capability (50mA) which is divided into four levels

ØLow code/zero code development, with EasyCodeCube embedded in the application template of intelligent dimming switch, which is able to quickly complete the product development


Key Features

Ø32K ROM, 4K RAM

ØIndustrial specification: wide voltage range: 2.0-5.5V, wide temperature range: -40~105

ØStrong anti-interference capability, ESD 6KV, EFT4KV

ØUp to 23 channels double-module touch circuit, passing 10V dynamic CS

ØOne independent UART, up to 3 USCIs (UART/SPI/IIC)

ØBuilt-in 1K Bootloader, supporting OTA upgrading

ØAll I/Os feature sink current drive capability (50mA) which is divided into four levels


       SinOne intelligent dimming switch solution is embedded with highly sensitive and reliable touchkey circuit, supporting multiple types of buttons/wheel/slider and easy to control the switch, color temperature and brightness...


Applicable Models

ØSC95F861XB/SC95F852X/SC92F846XB


Applicable Part Number

Add to compare

Compare(0)

export

3 total entries

  P/N PKG Type
ROM
(Byte)
RAM
(Byte)
EEPROM
(100K times)
BootLoader
Voltage
(V)
TK
(Max)
ADC
PWM
(with dead-time insertion)
PWM
UART
USCI
(UART/SPI/IIC)
SSI
(UART/SPI/IIC)
LCD/LED Driver
Touch Key Application type
Touch Key Performance
SC95F8523 SOP28/TSSOP28 32K 4K 1KB Built-in1K 2.0~5.5V 23 12bit*11ch 12bit*8ch - 1 3 - - Spring Buttons/Touchless Buttons/Proximity Sensing 10V dynamic CS EFT 4KV ESD 6KV
SC95F8616B LQFP44 64K 8K 6KB Built-in0/1/2/4K 2.0~5.5V 31 12bit*17ch 16bit*12ch - 1 5 - 8*24/6*26/5*27/4*28 Spring Buttons/Touchless Buttons/Proximity Sensing 10V dynamic CS EFT 4KV ESD 6KV
SC92F8463B SOP28/TSSOP28 16K 1K 128B - 2.4~5.5V 23 12bit*11ch - 10bit*6ch(Support complementary mode) 1 - 1 5COM Spring Buttons/Touchless Buttons/Proximity Sensing 10V dynamic CS /EFT 4KV
